The TC-4111-CS&S Single Bulb Thermostats are designed for on/off control of media temperatures in tanks, ducts, liquid lines, etc. A liquid-filled copper bulb at the end of capillary 6 feet long senses temperature and through a force balance system makes and breaks an SPDT switch. The switch has electrical ratings as noted below. The Setpoint Adjustment Range for this Thermostat is – 40 °F to 120 °F. The Differential for these units is factory set at 3 °F, but can be adjusted between 3 °F and 16 °F.
| Switch Ratings | 24 V | 120V | 240V |
|---|---|---|---|
| Full Load Amps | 9.8 | 9.8 | 8.0 |
| Locked Rotor Amps | 58.8 | 58.8 | 48 |
| Pilot Duty VA | 60 | 360 | 360 |
| Non-Inductive Amps (Resistive) | 22 | 22 | 22 |
Weights & Dimensions: Unit – 4-5/8” H X 2-3/8” W X 2” D (plus Bulb/Capillary)
Package* – 1.32#, 3” X 4-1/2” X 11-3/4”
Replaces:
| OEM Part Number | Supplier | Replaces |
|---|---|---|
| TC-4111-CS&S | Schneider Electric | TC-4111 |
Crandall Stats and Sensors is the OEM manufacturer of the TC-4111. These products are proudly manufactured by Crandall Stats and Sensors, Inc. in Machesney Park, Illinois, USA.
